Product Details:

TRICONEX 2658 is a high-performance communication module built with triple modular redundancy (TMR) architecture for Triconex Tricon safety instrumented systems (SIS). This TMR safety system module acts as the data gateway between the Tricon main processor and external automation platforms, equipped with dual 10/100Mbps isolated Ethernet ports to ensure stable data transmission. The Tricon communication module supports Modbus TCP, TriStation, FTP and IEC 60870-5-104 protocols, enabling real-time upload of safety logic variables, alarm events and SOE sequence of events data to DCS, SCADA, HMI and engineering workstations. It can be configured redundantly to improve communication reliability, and continuously monitors Ethernet link status, internal memory and hardware health. Once communication interruption or hardware abnormality is detected, fault signals will be sent to the engineering workstation immediately. The module supports hot swap operation, maintenance personnel can replace the faulty unit online without shutting down the whole safety system. Front panel LED indicators display power, link activity, fault and TriBus synchronization status for fast on-site inspection and troubleshooting. It is installed in the dedicated communication slot of standard Tricon rack and cooperates with Tricon processor and I/O modules. Widely applied in oil & gas, petrochemical, chemical and power industries, this TRICONEX 2658 communication module provides reliable data interaction services for ESD emergency shutdown, fire and gas detection and burner management safety interlock systems.

Specifications:

Manufacturer: TRICONEX (Schneider Electric)

Model: 2658

Product Type: Tricon Communication Module

System Compatibility: Tricon TMR Safety Instrumented System

Communication Ports: Dual 10/100 Base-T isolated Ethernet ports

Supported Protocol: Modbus TCP, TriStation, FTP, IEC 60870-5-104

Architecture: Triple Modular Redundancy(TMR), 2-out-of-3 voting

Safety Level: SIL3 certified

Isolation: 1500V isolation between communication interface and internal bus

Diagnostics: Communication link, memory and hardware fault real-time monitoring

Feature: Hot swappable, redundant dual module configuration supported

Status Indicator: POWER, LINK/ACT, FAULT, TRIBUS SYNC LED indicators

Mounting: Tricon rack dedicated communication slot plug-in

Operating Temperature: 0℃ ~ +60℃

Humidity: 5% to 95% non-condensing

Certifications: IEC61508, SIL3, CE
