Product Details:

The GE IS220PRTDH1B, part number 336A5026ADP13, is a high-precision RTD Input Pack Module designed for GE Speedtronic Mark VIe distributed turbine control systems. This industrial control spare part collects resistance signals from platinum RTD temperature sensors. As a reliable Turbine Control Module, it supports Pt100, Pt200, Pt500, Pt1000 sensors, compatible with 2-wire,3-wire and 4-wire wiring modes, with automatic lead resistance compensation. It converts resistance variation into accurate digital temperature data for monitoring bearing temperature, stator winding temperature and other thermal parameters of gas turbines, steam turbines and generators.

The GE IS220PRTDH1B RTD Input Pack Module is equipped with dual 100Mbps IONet Ethernet ports for redundant network communication. It supports simplex, dual and TMR redundant system architectures and allows hot replacement without full system shutdown. Front panel LED indicators display power status, communication link and channel faults in real time. Built-in channel diagnostic functions can detect sensor open circuit, short circuit and signal out-of-range faults. The module adopts conformal coated circuit board to resist vibration, dust and moisture in harsh power plant environments. It is widely used in power generation and oil & gas compressor stations for turbine control system maintenance, spare part replacement and system upgrade.

Specifications:

Brand: GE

Model: IS220PRTDH1B

Part Number:336A5026ADP13

Product Type: RTD Input Pack Module

Compatible System: GE Mark VIe Speedtronic Turbine Control System

Input Channels:8 independent RTD input channels

Supported Sensor: Pt100, Pt200, Pt500, Pt1000

Wiring Mode:2-wire,3-wire,4-wire

Communication:Dual 100Mbps IONet Ethernet

Power Supply:24VDC

Mounting:I/O rack mount

Protection Class:IP20

Operating Temperature:-30℃ ~ +65℃
