Product Details:

GE IC697CMM742-LL is a Type 2 high-performance Ethernet interface module developed for GE Fanuc Series 90-70 PLC system. This PLC communication module builds the Ethernet connection between the Series 90-70 PLC backplane and industrial local area network, supporting stable data transmission for industrial automation control. The Ethernet interface module runs at 10Mbps network speed and supports TCP/IP, SRTP, EGD and Modbus TCP protocols. It can realize real-time data exchange between multiple GE PLCs, HMI, SCADA and host computers running CIMPLICITY software, supporting up to 32 simultaneous SRTP network connections. It is equipped with multiple network interfaces including AUI port, 10Base2 BNC port and 10BaseT RJ45 port, together with RS232 station manager port and RS485 firmware loading port for module configuration, diagnosis and firmware upgrade. Front panel LED indicators display module running status, LAN connection and serial communication activity, helping maintenance staff quickly locate network faults. This Ethernet interface module occupies one single slot on Series 90-70 rack, powered by PLC backplane +5VDC and +12VDC power supply. It adopts flash memory to store firmware and network configuration parameters. Widely used in power plants, petrochemical, metallurgy and large factory automation projects, this GE IC697CMM742-LL module provides reliable Ethernet communication for distributed PLC control systems.

Specifications:

Manufacturer: GE Fanuc

Model: IC697CMM742-LL

Product Type: Type 2 Ethernet Interface Module

Applicable Series: Series 90-70 PLC

Network Speed: 10Mbps

Network Interfaces: AUI,10Base2 BNC,10BaseT RJ45

Serial Ports: RS232 station manager port, RS485 firmware load port

Supported Protocols: TCP/IP,SRTP,EGD,Modbus TCP

Max SRTP Connections: 32

Backplane Current: 1.5A @ +5VDC

Memory: Flash memory for firmware and configuration

Status Indicator: LED for module OK, LAN online, serial activity

Mounting: Single slot rack mount

Operating Temperature: 0℃ ~ +60℃

Humidity: 5% to 95% non-condensing

Certifications: UL,CE,CSA
