Product Details:

The GE IS230TCISH6C is a high-precision Thermocouple Input Terminal Board designed for GE Speedtronic Mark VIe turbine control systems. This industrial control spare part serves as the front-end signal conditioning interface for thermocouple temperature sensors installed on gas turbines and steam turbines. As a reliable Turbine Control Module, it supports multiple thermocouple types including J, K, T, E, R, S, B and N, and it is equipped with 16 differential input channels to collect weak millivolt temperature signals. It converts raw thermocouple signals into calibrated digital data and transmits the data to the Mark VIe I/O pack for real-time temperature monitoring of turbine exhaust, combustion chambers and bearing assemblies.

The GE IS230TCISH6C Thermocouple Input Terminal Board uses conformal coated PCB to resist moisture, dust and vibration in harsh power plant environments. It integrates cold junction compensation circuits to eliminate temperature measurement errors caused by terminal temperature changes. Built-in surge protection and channel diagnostic functions can detect open circuit sensor faults and report alarms promptly. The board is equipped with screw terminal blocks for convenient sensor wiring and on-site maintenance. It supports simplex, dual and TMR redundant system architectures and rack mounting inside Mark VIe control cabinets. It is widely used in power generation and oil & gas compressor stations, applied for turbine control system maintenance and spare part replacement.

Specifications:

Brand: GE

Model: IS230TCISH6C

Product Type: Thermocouple Input Terminal Board

Compatible System: GE Mark VIe Speedtronic Turbine Control System

Input Channels:16 differential thermocouple channels

Supported Thermocouple: J,K,T,E,R,S,B,N

Compensation: Built-in cold junction compensation

Mounting: I/O rack mount

Protection Class: IP20

Operating Temperature: -20℃ ~ +70℃

Weight: 0.6kg
