Product Details:

The GE IS230TBAIH2C is a high-performance Analog Input Terminal Board built for GE Mark VIe Speedtronic turbine control systems. This industrial control spare part is responsible for collecting 4-20mA analog current signals from field transmitters, including pressure, flow and temperature sensors. As a reliable Turbine Control Module, it converts analog field signals into digital data and transmits the data to the Mark VIe main controller for real-time monitoring and process regulation. It supports channel-to-channel isolation and field-to-backplane isolation, effectively reducing signal interference in power plant environments.

The GE IS230TBAIH2C Analog Input Terminal Board adopts conformal coated circuit board design to resist dust, moisture and corrosive gas. It is equipped with cage clamp screw terminals for convenient wiring and on-site maintenance. Built-in surge suppression circuits protect the board from voltage spikes and transient noise. This board can work under simplex, dual and TMR redundant system configurations, supporting hot replacement and built-in channel diagnostic functions to quickly locate signal faults. It is widely used in gas turbine, steam turbine and compressor control systems in power generation and oil & gas industries, used as replacement spare parts for routine maintenance and system upgrade.

Specifications:

Brand: GE

Model: IS230TBAIH2C

Product Type: Analog Input Terminal Board

Compatible System: GE Mark VIe Turbine Control System

Input Signal: 4-20mA current loop

Channel Isolation: Channel-to-channel and field-backplane isolation

System Configuration: Simplex, Dual, TMR

Mounting: I/O chassis rack mount

Protection Class: IP20

Operating Temperature: -20℃ ~ +70℃

Weight: 0.6kg
