Title: GE IS220PPRFH1A PROFIBUS Master Gateway Pack Module 336A4940CSP20 Mark VIe Inquiry Product

Three Keywords: PROFIBUS Master Gateway Pack Module, Turbine Control Module, Industrial Control Spare Part

Product Details:

The GE IS220PPRFH1A, part number 336A4940CSP20, is a PROFIBUS Master Gateway Pack Module designed for GE Speedtronic Mark VIe distributed turbine control systems. This industrial control spare part serves as the fieldbus communication gateway between Mark VIe controller and PROFIBUS-DP slave field devices. As a reliable Turbine Control Module, it adopts Hilscher COM-C communication chip, supports PROFIBUS DPV0 master protocol, with communication baud rate ranging from 9.6 KBaud up to 12 MBaud. It can connect up to 125 PROFIBUS slave devices, realizing bidirectional real-time data exchange between turbine control system and field transmitters, actuators and other intelligent instruments. It needs to cooperate with IS200SPIDG1A terminal board for complete signal termination.

The GE IS220PPRFH1A PROFIBUS Master Gateway Pack Module is equipped with dual 100Mbps IONet Ethernet ports for redundant network communication, ensuring stable data transmission with the main controller. It supports simplex, dual and TMR redundant system architectures and allows hot replacement without full system shutdown. Front panel LED indicators display power status, IONet link and PROFIBUS bus communication faults in real time. Built-in comprehensive bus diagnostic functions can detect bus short circuit, slave station dropout and communication abnormal faults. The module adopts conformal coated circuit board to resist vibration, dust and moisture in harsh power plant environments. It is widely used in power generation and oil & gas compressor stations for turbine control system maintenance, spare part replacement and system upgrade.

Specifications:

Brand: GE

Model: IS220PPRFH1A

Part Number:336A4940CSP20

Product Type: PROFIBUS Master Gateway Pack Module

Compatible System: GE Mark VIe Speedtronic Turbine Control System

Fieldbus Protocol: PROFIBUS DPV0 Master

Baud Rate:9.6KBaud ~12MBaud

Max Slave Quantity:125 PROFIBUS slave devices

Communication:Dual 100Mbps IONet Ethernet

Connector:DE-9 D-sub for PROFIBUS

Matched Terminal Board:IS200SPIDG1A

Power Supply:24VDC

Mounting:I/O rack mount

Protection Class:IP20

Operating Temperature:-20℃ ~ +65℃
