Product Details:

The GE IS215ACLEH1A paired with IS200ACLEH1AAA carrier board forms a complete Application Control Layer Module (ACLE), developed for GE Speedtronic Mark VI turbine control systems and EX2100 generator excitation control systems. This industrial control spare part acts as the core application computing unit of the excitation rack. As a reliable Turbine Control Module, it is equipped with 100MHz 486 industrial processor, running QNX real-time operating system. It executes AVR automatic voltage regulation, PSS power system stabilization, generator synchronization and excitation closed-loop control algorithms. It communicates with DSPX digital signal processor boards via high-speed ISBus, exchanges real-time operational data with HMI and distributed I/O boards through dual 10Base-T Ethernet ports, and handles sequence control, fault recording and system diagnostic tasks for generators.

The GE IS215ACLEH1A and IS200ACLEH1AAA assembly adopts conformal coated PCB to resist dust, moisture and vibration in harsh power plant environments. It is equipped with dual 10Base-T Ethernet ports, two RS232 COM serial ports and compact flash storage for firmware and parameter storage. Front panel LED indicators show module active status, network link and hardware fault alarms. The assembly supports simplex, dual and TMR redundant system architectures and VME rack mounting inside EX2100 control cabinet. Built-in comprehensive self-diagnostic functions can detect processor, memory, bus and communication faults timely. It is widely used in power generation and oil & gas industries for gas turbine, steam turbine generator excitation control system maintenance, spare part replacement and system retrofit.

Specifications:

Brand: GE

Model: IS215ACLEH1A, IS200ACLEH1AAA

Product Type: Application Control Layer Module Assembly

Compatible System: GE Mark VI Speedtronic Turbine Control System, EX2100 Excitation Control System

CPU: 100MHz 486 industrial processor

Operating System: QNX real-time operating system

Interface: Dual 10Base-T Ethernet, 2 x RS232 COM ports, ISBus high-speed bus

Storage: Compact flash, on-board DRAM, DPRAM

Form Factor:6U VME board assembly

Mounting: VME rack mount

Protection Class:IP20

Operating Temperature:-20℃ ~ +70℃

Weight:1.2kg
