Product Details:

The GE IS210AEDBH4AGD is an Analog Excitation Device Bridge Interface Board developed for GE Speedtronic Mark VI turbine control systems, and it can match with EX2100 excitation control system. This industrial control spare part works as the signal bridge between main controller and generator excitation equipment. As a reliable Turbine Control Module, it is equipped with Bicron pulse transformers with 5kVAC hipot rating, handling excitation voltage and current feedback signals. It collects field measurement data of generator excitation and outputs control signals to adjust excitation current, to stabilize generator terminal voltage and reactive power output. It integrates multi-stage filter circuits to suppress high frequency noise interference in power plant sites.

The GE IS210AEDBH4AGD Analog Excitation Device Bridge Interface Board adopts conformal coated PCB, equipped with multiple types of pin headers and right-angle cable connectors for convenient wiring and field maintenance. The board contains more than 175 integrated circuits, with on-board jumpers for function configuration. It supports simplex, dual and TMR redundant system architectures and VME rack installation inside Mark VI control cabinet. Built-in circuit monitoring and fault detection functions help operators find abnormal board status quickly. It is widely used in power generation and oil & gas industries for gas turbine, steam turbine and generator excitation control system maintenance, spare part replacement and system retrofit.

Specifications:

Brand: GE

Model: IS210AEDBH4AGD

Product Type: Analog Excitation Device Bridge Interface Board

Compatible System: GE Mark VI Speedtronic Turbine Control System, EX2100 Excitation Control System

Transformer: Bicron pulse transformer,5kVAC hipot rating

Connector: Right-angle cable connector, multi pin header

Mounting: VME rack mount

Protection Class: IP20

Operating Temperature: -20℃ ~ +70℃

Weight: 0.5kg
