Product Details:

The GE IS200TBCIS2CCD is a group-isolated Contact Input Terminal Board designed for GE Speedtronic Mark VI turbine control systems. This industrial control spare part acts as the field signal interface, collecting dry contact on/off signals from limit switches, auxiliary contacts and field sensors. As a reliable Turbine Control Module, it comes with 24 dry contact input channels with group electrical isolation, which effectively prevents cross-channel interference and protects the main control board from external voltage surges. It transfers discrete contact status to the PDIA digital input board for turbine protection, sequence control and interlock logic processing.

The GE IS200TBCIS2CCD Contact Input Terminal Board uses conformal coated PCB to resist dust, moisture and vibration in power plant environments. Barrier type terminal blocks are arranged on the board for convenient wiring and on-site maintenance. It supports simplex, dual and TMR redundant system architectures. The board can be installed inside the VME rack of Mark VI control cabinet. Built-in signal filtering circuits reduce electromagnetic noise interference. It is widely used in gas turbine, steam turbine and compressor control systems in power generation and oil & gas industries, used for maintenance replacement and system retrofit.

Specifications:

Brand: GE

Model: IS200TBCIS2CCD

Product Type: Contact Input Terminal Board

Compatible System: GE Mark VI Speedtronic Turbine Control System

Input Channels:24 dry contact input channels

Isolation: Group isolation

Terminal Type: Barrier terminal block

Mounting: VME rack mount

Power Supply:125VDC contact excitation

Protection Class: IP20

Operating Temperature: -20℃ ~ +70℃
