Product Details:

GE IC693DNM200 is a single-slot DeviceNet master communication module developed for GE Fanuc Series 90-30 PLC system. This PLC communication module acts as the network master node, enabling the Series 90-30 PLC to communicate with various DeviceNet slave field devices such as sensors, actuators, variable frequency drives and remote I/O units. The DeviceNet master module supports multiple baud rates including 125Kbps, 250Kbps and 500Kbps, and can connect up to 63 slave devices on one DeviceNet network. It is equipped with a 9-pin RS232 service port for local configuration, network diagnosis and firmware upgrade. Built-in network diagnostic LEDs help engineers quickly check network running status and locate communication faults. The module supports up to 32 input points and 32 output points data exchange between PLC and field slave devices, realizing real-time acquisition of field signals and control command output. It adopts plug-in rack mounting design and occupies only one slot on the Series 90-30 baseplate, easy for installation and system expansion. This DeviceNet master module is widely used in automotive manufacturing, material handling, packaging machinery and factory automation projects, building stable DeviceNet fieldbus network for distributed industrial control.

Specifications:

Manufacturer: GE Fanuc

Model: IC693DNM200

Product Type: DeviceNet Master Module

Applicable Series: Series 90-30 PLC

Network Protocol: DeviceNet

Baud Rate: 125Kbps,250Kbps,500Kbps

Max Slave Nodes: 63

I/O Data: 32 input points,32 output points

Service Interface: RS232 9-pin D-sub connector

Module Size: Single slot

Mounting: Rack plug-in

Power Supply: 12-24VDC

Operating Temperature: 0℃ ~ +60℃

Humidity: 5% to 95% non-condensing

Certifications: UL,CE
