Product Details:

The GE DS200SDCCF1AFD is a high-reliability SDCC Drive Control Board for GE Speedtronic Mark V turbine control and EX2000 excitation systems. This industrial control spare part adopts triple 16-bit microprocessor architecture with dual port RAM. It executes drive closed-loop regulation, analog and digital I/O processing and encoder signal acquisition. It communicates with other Mark V boards via LAN bus, outputs control commands for excitation rectifier, and implements generator excitation adjustment for gas turbines and steam turbines.

The GE DS200SDCCF1AFD SDCC Drive Control Board adopts conformal coated PCB to resist dust, moisture and vibration in harsh power plant environments. It has multiple configurable jumpers for hardware setup. Onboard LED indicators show operating status and fault codes. The board supports simplex, dual and TMR redundant system architectures and rack mounting inside Mark V control cabinet. Built-in self-diagnostic functions can detect processor faults, bus interruption and signal circuit abnormalities. It is widely used in power generation and oil & gas industries for generator excitation control system maintenance, spare part replacement and system retrofit.

Specifications:

Brand: GE

Model: DS200SDCCF1AFD

Product Type: SDCC Drive Control Board

Compatible System: GE Mark V Speedtronic Turbine Control System, EX2000 Excitation System

Onboard Processors: Three 16-bit microprocessors

Memory: Dual port RAM

Function: Drive closed-loop control, I/O processing, encoder signal acquisition, fault diagnosis

Mounting: Rack mount

Protection Class:IP20

Operating Temperature:-20℃ ~ +70℃

Weight:1.0kg
