Product Details:

The BENTLY NEVADA 3500/05-02-05-00-00-01 system rack is a 12-inch mini chassis designed as the hardware backbone for the Bently Nevada 3500 machinery protection TSI system. This machinery protection rack provides 7 module slots and two dedicated half-height power supply positions, supporting the installation of various monitor modules, relay modules, Keyphasor modules and communication modules. The system rack integrates a passive high-speed backplane bus, which realizes power distribution and inter-module data communication between all inserted modules. It adopts rack mounting structure, compact size for installation in limited control cabinet space. The robust metal chassis provides good mechanical protection and electromagnetic shielding, resisting vibration and interference in industrial environments. It supports hot swap of individual modules without powering down the whole rack system. The rack can be configured to form complete rotating machinery protection systems, continuously monitoring shaft vibration, bearing temperature, shaft position and other critical parameters. It is widely used in steam turbines, compressors, generators, pumps and fans within petrochemical, power generation and metallurgy industries, serving as the core chassis for equipment safety protection and condition monitoring.

Brand: Bently Nevada

Model:3500/05-02-05-00-00-01

Product Type: 3500 Series Mini System Rack

Size:12-inch mini rack

Module Slots:7 slots for monitor and communication modules

Power Slots:2 half-height power supply slots

Backplane:Passive high-speed backplane bus

Mounting:Rack mount option

Feature:Compact chassis,EMI shielding,support module hot swap

Application:Bently Nevada 3500 machinery protection TSI system
