Product Details:

The BENTLY NEVADA 1900/65A general purpose equipment monitor is a compact standalone machinery condition monitoring unit from Bently Nevada 1900 series, adopting DIN rail installation for cabinet mounting. This vibration temperature monitoring device integrates 4 transducer input channels and 4 temperature input channels. The transducer channels support proximity probes, accelerometers and velocity sensors, while temperature channels accept RTD and E/J/K/T type thermocouple signals. Users can configure measurement parameters and independent Alert / Danger alarm thresholds via dedicated PC configuration software. It is equipped with 6 programmable SPDT relay outputs, 4 channels of 4-20mA recorder outputs and buffered transducer signal outputs for waveform analysis. Optional Modbus communication function including Modbus TCP Ethernet and Modbus RTU RS485 is available for data uploading to DCS, PLC, SCADA and System 1 diagnostic software. It supports an optional remote display module, which can be installed up to 75 meters away from the main unit. Built-in continuous self-diagnosis function detects sensor open circuit, short circuit and internal hardware faults automatically. It stores up to 200 event logs for fault traceability. Different suffix codes define power supply type, display option and communication configuration. It is widely used for fans, pumps, small compressors and auxiliary rotating equipment in petrochemical, power generation and metallurgy industries, providing economical online condition monitoring and protection.

Brand: Bently Nevada

Model:1900/65A

Product Type: Standalone General Purpose Equipment Monitor

Input:4 transducer channels,4 temperature channels

Output:6 SPDT relay outputs,4×4-20mA,buffered transducer output

Communication:Optional Modbus TCP / Modbus RTU

Power Supply:18~36VDC,AC power option available

Mounting:DIN rail or bulkhead mounting

Feature:Compact standalone design,configurable alarm setpoints,event logging,self-diagnosis,optional remote display

Application:Rotating machinery vibration and bearing temperature monitoring for pumps, fans and compressors
