Product Details:

The BENTLY NEVADA 1900/65A-01-00-01-00-01 general purpose equipment monitor is a compact standalone machinery monitoring unit, different from the rack-mounted 3500 series modules. This vibration temperature monitoring device comes with four transducer input channels and four temperature input channels, supporting signals from proximity probes, accelerometers, velocity sensors, RTD and thermocouples. Users can configure each channel through dedicated software to measure shaft vibration, casing vibration, bearing temperature and other machinery parameters. It integrates six relay output channels, four 4-20mA analog recorder outputs and buffered transducer signal output for waveform analysis. The unit supports Modbus communication over Ethernet and RS485 serial port, which can connect to DCS, PLC, SCADA and System 1 software to upload real-time measurement data and alarm events. The suffix code 01 represents 110~220VAC power supply option, 00 means no local display, 01 with Modbus communication. It adopts DIN rail mounting structure for installation in control cabinets. Built-in continuous self-diagnosis function detects sensor faults and internal hardware abnormalities. It can set independent alert and danger alarm thresholds for each channel, and trigger relay protection action when parameters exceed limits. It is widely used for fans, pumps, compressors and small steam turbines in petrochemical, power generation and metallurgy industries, providing cost-effective rotating machinery condition monitoring and protection.

Brand: Bently Nevada

Model:1900/65A-01-00-01-00-00

Product Type: General Purpose Equipment Monitor

Input Channels:4 transducer channels,4 temperature channels

Output:6 relay outputs,4 channels 4-20mA,buffered transducer output

Communication:Ethernet Modbus,RS485 Modbus

Power Supply:110~220VAC

Mounting:DIN rail installation

Feature:Multi-signal input,Modbus communication,onboard relay and analog output,self-diagnosis,compact standalone monitor

Application:Rotating machinery vibration and bearing temperature monitoring for pumps, fans and compressors
