Product Details:

TRICONEX CM3201 is a high-performance communication module designed for Triconex Trident safety instrumented systems (SIS). This TMR safety communication module acts as the data exchange gateway between the safety controller and external systems, realizing bidirectional data transmission between the Tricon safety system, DCS, HMI, TriStation workstation and other host equipment. The module is equipped with 2 Ethernet ports and 3 RS232/RS485 serial ports, supporting multiple communication protocols including Modbus TCP, Modbus RTU and TSAA proprietary safety protocol. It can be configured in redundant communication mode to avoid single communication path failure and improve the stability of safety data transmission. The module supports continuous self-diagnosis function, which can monitor communication link status in real time and report communication fault alarms to the main processor. It supports hot swap operation, maintenance personnel can replace the faulty module online without shutting down the whole safety system, reducing system downtime. It cooperates with Tricon main chassis, processor modules and matched shielded cable assemblies. Widely applied in oil & gas, petrochemical, chemical and power industries, this TRICONEX CM3201 communication module undertakes safety system data interaction work for ESD emergency shutdown, fire and gas detection and burner management safety interlock systems.

Specifications:

Manufacturer: TRICONEX

Model: CM3201

Product Type: Tricon Safety Communication Module

Interface: 2 Ethernet ports, 3 RS232/RS485 serial ports

Supported Protocol: Modbus TCP, Modbus RTU, TSAA

Rated Voltage: 24VDC(19.2~30VDC)

Max Power Consumption: 8W

Feature: Redundant communication configuration, hot swappable, continuous link diagnosis, DIN rail mounting

Operating Temperature: 0℃ ~ +60℃

Humidity: 5% to 95% non-condensing
