Product Details:

TRICONEX FTA-544 is a field termination assembly (FTA) designed for Triconex safety instrumented systems (SIS). This TMR safety termination unit serves as the signal wiring interface between Tricon I/O modules and field instruments, realizing safe signal transmission for analog and digital signals. It supports 4-20mA analog loop signals and discrete digital switch signals, providing built-in channel isolation, short-circuit protection and field transmitter power supply circuit for field devices. The FTA follows TMR safety design matching the 2-out-of-3 voting principle of Tricon controller, which can maintain signal integrity when single redundant path fails and reduce single point failure risk. It has terminal block layout for convenient field wiring, and each channel is equipped with test points for circuit inspection and fault troubleshooting. The assembly works with corresponding analog output modules, and supports continuous circuit self-diagnosis to detect open circuit and short circuit faults on field wiring loops. It cooperates with Tricon main chassis, I/O modules and shielded cable assemblies. Widely applied in oil & gas, petrochemical, chemical and power industries, this TRICONEX FTA-544 field termination assembly undertakes field signal wiring and protection work for ESD emergency shutdown, fire and gas detection and burner management safety interlock systems.

Specifications:

Manufacturer: TRICONEX

Model: FTA-544

Product Type: Tricon Field Termination Assembly

Supported Signal: 4~20mA analog signal, discrete digital signal

Safety Level: SIL3 capable

Power Supply: 24VDC field transmitter power supply

Feature: Signal isolation, per-channel short-circuit protection, built-in test points, easy field wiring, SIL3 capable

Operating Temperature: 0℃ ~ +60℃

Humidity: 5% to 95% non-condensing
