Product Details:

TRICONEX ICM6211 is a redundant communication interface module designed for Triconex TMR safety instrumented systems (SIS). This TMR safety module acts as the data exchange gateway between the safety controller and external devices, realizing bidirectional data transmission between Tricon safety system, DCS, HMI and host workstation. The module adopts triple modular redundant 2-out-of-3 voting architecture, supporting redundant communication configuration for bumpless switchover when one communication channel fails, removing single point failure risk. It supports Modbus RTU, Modbus ASCII and Tricon proprietary communication protocols, achieving stable data interaction between safety system and third-party intelligent equipment. Built-in continuous self-diagnosis function can monitor communication link status in real time, detect link disconnection and signal abnormality, and upload fault alarm information to the safety controller. The module supports hot swap operation, maintenance personnel can replace the faulty module online without shutting down the whole safety system, minimizing system downtime. It cooperates with Tricon main chassis, processor modules and matched shielded cable assemblies. Widely applied in oil & gas, petrochemical, chemical and power industries, this TRICONEX ICM6211 communication interface module undertakes reliable data transmission work for ESD emergency shutdown, fire and gas detection and burner management safety interlock systems.

Specifications:

Manufacturer: TRICONEX

Model: ICM6211

Product Type: Tricon Redundant Communication Interface Module

Protocol Support: Modbus RTU, Modbus ASCII, Tricon proprietary protocol

Rated Power Supply: 24VDC

Safety Level: SIL3 capable

Feature: Triple modular redundancy, hot swappable, redundant communication switchover, continuous link self-diagnosis, rack mount design

Operating Temperature: 0℃ ~ +60℃

Humidity: 5% to 95% non-condensing
