TRICONEX 4101 also known as ICM4101 is an inter-cabinet communication module built with triple modular redundancy (TMR) architecture for Triconex Tricon safety instrumented systems (SIS). This TMR safety module is used to establish reliable high-speed communication links between the main controller cabinet and remote I/O cabinets in distributed SIS configurations. The Tricon inter-cabinet communication module is equipped with dual redundant highway ports, running the proprietary Tricon inter-cabinet highway protocol at 1Mbps transmission speed. It performs 2-out-of-3 voting on all transmitted and received data to eliminate single point of failure and guarantee data integrity. It continuously monitors communication link health, signal quality and internal hardware status. If cable breakage, link interruption or hardware failure occurs, fault alarms will be immediately sent to the Tricon engineering workstation. The module supports hot swap operation, maintenance personnel can replace the faulty module online without shutting down the whole safety system. Front panel LED indicators display module power, link activity and fault status for fast on-site inspection and troubleshooting. It can be installed in dedicated communication slots of standard Tricon rack and cooperates with Tricon processor and all series I/O modules. Widely applied in oil & gas, petrochemical, chemical and power industries, this TRICONEX 4101 communication module realizes reliable data exchange between multi-cabinet Tricon systems for ESD emergency shutdown, fire and gas detection and burner management safety interlock systems.

Specifications:

Manufacturer: TRICONEX (Schneider Electric)

Model: 4101 (ICM4101)

Product Type: Tricon Inter-Cabinet Communication Module

System Compatibility: Tricon TMR Safety Instrumented System

Communication Ports: Dual redundant highway ports

Transmission Speed: 1 Mbps

Max Cable Length: 1000 meters per segment

Architecture: Triple Modular Redundancy(TMR), 2-out-of-3 voting

Safety Level: SIL3 certified

Isolation: 1500V isolation between communication port and backplane

Diagnostics: Communication link and hardware continuous fault monitoring

Feature: Hot swappable, dual redundant port design

Status Indicator: POWER, LINK, FAULT LED indicators

Mounting: Tricon rack dedicated communication slot plug-in

Operating Temperature: 0℃ ~ +60℃

Humidity: 5% to 95% non-condensing

Certifications: IEC61508, SIL3, CE
