Product Details:

TRICONEX 3451 also known as DI3451 is a 16-channel TMR digital input module built with triple modular redundancy (TMR) architecture for Triconex Trident safety instrumented systems (SIS). This TMR safety I/O module collects 24VDC discrete signals from field emergency stop buttons, pressure switches, limit switches and dry contact sensors, and converts these on-site status signals into digital data and transmits to the Trident main controller. The Trident digital input module adopts independent channel galvanic isolation design to resist ground loop noise and electromagnetic interference from long field wiring. Continuous built-in channel diagnostics can detect open circuit, short circuit and internal hardware anomalies, and send fault alarm information to the Trident engineering workstation in real time. The module supports hot swap operation, maintenance personnel can replace the faulty unit online without shutting down the whole safety system. Front panel LED indicators display module health status and each channel signal state for fast on-site inspection and troubleshooting. It adopts 2-out-of-3 voting logic to eliminate single point of failure and fully meets SIL3 safety integrity level requirements. It can be installed in standard Trident rack and cooperates with Trident processor and other I/O modules. Widely applied in oil & gas, petrochemical, chemical and power industries, this TRICONEX 3451 digital input module is used for ESD emergency shutdown, fire and gas monitoring and burner management safety control systems.

Specifications:

Manufacturer: TRICONEX (Schneider Electric)

Model: 3451 (DI3451)

Product Type: Trident 16-channel Digital Input Module

System Compatibility: Trident TMR Safety Instrumented System

Input Channels: 16 isolated digital input channels

Nominal Input Voltage: 24VDC

Architecture: Triple Modular Redundancy(TMR), 2-out-of-3 voting

Safety Level: SIL3 certified

Isolation: Channel electrical isolation

Diagnostics: Open circuit, short circuit and hardware fault detection

Feature: Hot swappable

Status Indicator: LED indicators for module health and each channel state

Mounting: Trident rack plug-in

Operating Temperature: 0℃ ~ +60℃

Humidity: 5% to 95% non-condensing

Certifications: IEC61508, SIL3, CE
