The BENTLY NEVADA 3500/93-03-01-00-00 display interface module(DIM) belongs to Bently Nevada 3500 TSI machinery protection system. The suffix -03 represents rear termination I/O type, -01 is standard RS422 communication, -00-00 are default configuration options without special certifications. This full-height hot-swappable module occupies one slot inside the 3500 rack. It collects vibration, displacement, temperature, speed, alarm status and rack event logs from all monitor modules via rack backplane, and transmits data to local LCD display panel through RS422 serial bus. One DIM module can support up to two 3500 local display units for redundant on-site monitoring. Operators can view real-time measurement values, active alarms and historical fault events on the local display without PC connection. Users can set display groups and alarm view parameters via 3500 rack configuration software. Front panel LED indicators display module OK status and communication link status for on-site inspection. Built-in self-diagnosis function can detect module hardware fault and communication interruption faults. It supports hot swapping during normal rack operation, maintenance staff can replace the module without shutting down the whole TSI system. It complies with API 670 turbomachinery monitoring standard, widely applied in petrochemical, power generation and metallurgy industries, matched with steam turbines, gas turbines and centrifugal compressors, used for local data display and alarm checking of rotating machinery protection rack.

Brand:Bently Nevada

Model:3500/93-03-01-00-00

Product Type:Full-height Display Interface Module(DIM)

Installation:Any free slot of 3500 system rack

Communication:RS422 serial for local display panel

Feature:rear termination,support max 2 display panels,hot swappable,self-diagnosis,API 670 compliant,standard non-certified version

Application:Bently Nevada 3500 machinery protection rack local display data transmission
