Product Details:

The BENTLY NEVADA 3500/62 six-channel process variable monitor module belongs to Bently Nevada 3500 TSI machinery protection system. This module can be installed in any free slot of the 3500 rack. It accepts 4-20mA current signals or -10Vdc ~ +10Vdc voltage signals from transmitters, used for pressure, flow, liquid level and auxiliary temperature measurement. The module supports three I/O types: ±10Vdc input, isolated 4-20mA input, and 4-20mA with intrinsic safety barrier. Six channels are configured via 3500 rack configuration software, users can set independent Alert and Danger alarm thresholds for each channel. When the process variable exceeds the preset value, the module sends alarm signals to rack relay modules to trigger machinery alarm or shutdown interlock. It supports TMR triple modular redundant configuration by installing three adjacent modules. It cooperates with TDI module to upload analog data to System 1 software for correlation analysis between process parameters and vibration data. Front panel LED indicators display module OK status, bypass state and each channel alarm state for on-site inspection. Built-in self-diagnosis function can detect sensor open circuit, short circuit and signal loss faults. It supports hot swapping during normal rack operation, maintenance staff can replace the module without shutting down the whole TSI system. It complies with API 670 turbomachinery monitoring standard, widely applied in petrochemical, power generation and metallurgy industries, matched with steam turbines, gas turbines and centrifugal compressors, used for rotating machinery process variable protection monitoring.

Brand:Bently Nevada

Model:3500/62

Product Type:Full-height 6-channel Process Variable Monitor Module

Installation:Any free slot of 3500 system rack

Input:4-20mA / -10Vdc ~ +10Vdc analog signal

Feature:6 channels,support 4-20mA and ±10Vdc,TMR configurable,hot swappable,self-diagnosis

Application:Bently Nevada 3500 machinery protection rack pressure,flow and liquid level monitoring
