Product Details:

TRICONEX 9651-110 is a basic digital output and relay output termination panel built for Triconex TMR safety instrumented systems (SIS). This TMR safety field terminal panel serves as the wiring bridge between Tricon digital output modules and field actuators, transmitting safety output control signals from I/O modules to on-site field devices. The termination panel supports 16 signal channels, and is compatible with Tricon 3601E, 3603E, 3623, 3636R and 3636T digital and relay output modules. It adopts industrial PCB and high-quality screw terminals, featuring stable contact performance and strong anti-vibration and anti-electromagnetic interference capability to adapt to harsh industrial cabinet environments. Each channel is equipped with independent signal routing design, convenient for field wiring, circuit inspection and fault troubleshooting. It cooperates with Tricon main chassis, digital output modules and matched shielded cable assemblies. Widely applied in oil & gas, petrochemical, chemical and power industries, this TRICONEX 9651-110 termination panel undertakes field output wiring work for ESD emergency shutdown, fire and gas detection and burner management safety interlock systems.

Specifications:

Manufacturer: TRICONEX

Model: 9651-110

Product Type: Tricon Digital Output Termination Panel

Signal Points: 16 points

Compatible Module: 3601E,3603E,3623,3636R,3636T

Feature: Screw terminal connection, DIN rail mounting, convenient circuit maintenance

Operating Temperature: -20℃ ~ +70℃

Humidity: 5% to 95% non-condensing
