Product Details:

TRICONEX 9561-810 is a 115V commoned digital input termination panel designed for Triconex TMR safety instrumented systems (SIS). This TMR safety field terminal panel establishes the wiring interface between Tricon digital input modules and on-site field sensors, collecting 16 points of digital input signals and transmitting stable signals to the safety control I/O modules. The termination panel adopts industrial PCB with built-in fuse protection for each channel, which can cut off abnormal current rapidly when short circuit occurs to protect the rear I/O module. It is equipped with gold-plated terminal connectors to reduce contact resistance and improve vibration resistance for long-term stable operation in industrial harsh environments. The panel is compatible with Tricon 3501E and 3501T digital input modules, realizing reliable signal transmission for safety control loops. It cooperates with Tricon main chassis, digital input modules and shielded cable assemblies. Widely applied in oil & gas, petrochemical, chemical and power industries, this TRICONEX 9561-810 termination panel handles field signal wiring for ESD emergency shutdown, fire and gas detection and burner management safety interlock systems.

Specifications:

Manufacturer: TRICONEX

Model: 9561-810

Product Type: 115V Commoned Digital Input Termination Panel

Signal Points: 16 points

Compatible Module: 3501E,3501T

Channel Protection: Individual fuse for each signal channel

Feature: Gold-plated terminals, channel fuse protection, DIN rail mounting

Operating Temperature: -20℃ ~ +70℃

Humidity: 5% to 95% non-condensing
