Product Details:

TRICONEX 3704E V7768-322001 is a 64-channel high density analog input module adopting triple modular redundancy (TMR) architecture for Triconex Tricon safety instrumented systems (SIS). This TMR safety I/O module collects voltage analog signals from field pressure, temperature and flow transmitters, converts analog signals into digital data and transmits to the Tricon main controller. The Tricon high density analog input module supports 0~5VDC and 0~10VDC input ranges, with 12-bit resolution and 75ms input update rate, and the measurement accuracy is less than 0.25% full scale. It is a commoned input design, which helps save cabinet space and reduce wiring cost for large quantity analog signal acquisition. Continuous built-in channel diagnostics can detect open circuit, short circuit and internal hardware faults, and transmit fault alarms to the engineering workstation in real time. The module supports hot swap operation, maintenance workers can replace the faulty module online without shutting down the safety system. Front panel LED indicators display module health status and channel signal state for fast on-site troubleshooting. It adopts 2-out-of-3 voting logic to eliminate single point of failure, fully meets SIL3 safety integrity level requirements. V7768-322001 is the part number variant of 3704E module. It can be installed in standard Tricon rack and matched with Tricon controller and other I/O modules. Widely applied in oil & gas, petrochemical, chemical and power industries, this TRICONEX 3704E V7768-322001 analog input module is used for ESD emergency shutdown, fire and gas monitoring and other safety-critical control systems.

Specifications:

Manufacturer: TRICONEX (Schneider Electric)

Model: 3704E V7768-322001

Product Type: Tricon 64-channel High Density Analog Input Module

System Compatibility: Tricon TMR Safety Instrumented System

Input Channels: 64 commoned analog input channels

Input Range: 0~5VDC,0~10VDC

Resolution:12-bit

Update Rate:75ms

Accuracy: <0.25% full scale

Architecture: Triple Modular Redundancy(TMR), 2-out-of-3 voting

Safety Level: SIL3 certified

Diagnostics: Open circuit, short circuit and hardware fault detection

Feature: Hot swappable

Status Indicator: LED indicators for module health and channel status

Mounting: Tricon rack plug-in

Operating Temperature: 0℃ ~ +60℃

Humidity: 5% to 95% non-condensing

Certifications: IEC61508, SIL3, CE
