Product Details:

The BENTLY NEVADA 3500/22-01-02-00 transient data interface module (TDI) is a full-height communication card for Bently Nevada 3500 TSI machinery protection rack system. The suffix -01 represents standard TDI mainboard, -02 stands for 100Base-FX fiber optic I/O interface, -00 means no special agency certification for ordinary control room environments. This module must be installed in rack slot 1 beside the power supply, and every 3500 rack needs one TDI module. It collects real-time measurement values, channel alarm status, module health signals and high-speed transient waveform data from all monitor cards on the rack backplane. It supports Bently proprietary protocol, realizing rack parameter download, real-time data reading and waveform capture when connecting with 3500 configuration software and System 1 fault diagnosis software. The 100Base-FX fiber interface supports long-distance signal transmission, effectively isolating electromagnetic interference and suitable for long-distance control room connection. Static data acquisition comes as standard, and high-resolution dynamic waveform capture needs optional channel license. The TDI is not part of the safety trip path; module failure will not affect the vibration, temperature and relay protection logic of the rack. Front panel LED indicators display module OK status and fiber link communication activity for routine inspection. The module supports hot swapping under normal rack operation, maintenance staff can replace the module without shutting down the whole TSI system. It complies with API 670 turbomachinery monitoring standard, widely applied in petrochemical, power generation and metallurgy industries, matched with steam turbines, gas turbines and centrifugal compressors, used for rack system configuration, real-time monitoring and fiber-optic data transmission.

Brand: Bently Nevada

Model:3500/22-01-02-00

Product Type:Transient Data Interface TDI Module

Installation:Slot 1 of 3500 rack,next to power supply

Interface:100Base-FX fiber optic

Feature:Fiber communication,long distance transmission,anti-electromagnetic interference,support steady-state and transient waveform capture,hot swappable,self-diagnosis,not part of safety trip path,standard non-certified version

Application:Bently Nevada 3500 machinery protection rack fiber-optic data communication and system configuration
