Product Details:

The BENTLY NEVADA 3500/05-01-02-00-00-01 is the full-size 14-slot system rack for Bently Nevada 3500 TSI machinery protection system, which is the basic hardware carrier of the whole monitoring and protection system. This rack adopts standard 19-inch EIA cabinet mounting structure, built-in high-speed backplane bus, responsible for power distribution and high-speed data communication between all internal plug-in modules. The suffix code -01 stands for rack mounting style, -02 represents 14 available module slots, -00-00 means no special agency certification, and the last -01 is the factory configuration version. Users can freely install power supply modules, TDI communication cards, vibration monitor, temperature monitor, overspeed monitor and relay output modules in the slots according to project requirements, and it can be built into TMR triple redundant safety architecture by three-rack configuration for high-reliability turbomachinery protection projects. The backplane bus realizes real-time data exchange between all monitor cards, relay modules and communication modules, transmitting measurement values, alarm status and module health signals. The rack supports dual redundant power supply installation to avoid system shutdown caused by single power supply failure. The metal chassis adopts anti-vibration and electromagnetic shielding design, which can resist interference in harsh industrial cabinet environments. The rack has built-in status indicator LEDs on the front panel, showing rack power and backplane operating status for convenient daily inspection. All modules support hot swapping under normal rack operation, and hardware replacement will not affect the safety trip logic of the whole TSI system. It meets API 670 turbomachinery protection standard, widely applied in petrochemical, power generation and metallurgy industries, matched with steam turbines, gas turbines and centrifugal compressors, providing stable rack platform for large rotating machinery online monitoring and safety protection.

Brand: Bently Nevada

Model:3500/05-01-02-00-00-01

Product Type:14-slot Full-size System Rack

Installation:19-inch standard cabinet mount

Backplane:High speed internal communication bus

Feature:14 module slots,dual redundant power supply support,anti-interference metal chassis,TMR architecture optional,hot swappable for all modules,API 670 compliant

Application:Bently Nevada 3500 machinery protection system rack for turbine and compressor monitoring
