Product Details:

The BENTLY NEVADA 3500/01-129133-01 is the official rack configuration software package for the Bently Nevada 3500 TSI machinery protection rack system. It is the essential tool for engineers to complete rack hardware recognition, channel function setup, alarm threshold configuration and system parameter download. Users can define each monitor channel measurement function, set Alert and Danger alarm values, configure relay voting logic, transient waveform capture parameters and communication protocol settings through this software. After configuration editing, the software downloads the complete parameter set to the rack backplane, and supports online reading of rack real-time data, module health status and historical alarm events for debugging and verification. It supports offline configuration function, users can build the whole rack project on PC without connecting hardware in advance, which greatly shortens the on-site commissioning cycle. The software also provides system diagnostic view, helping maintenance staff to check sensor faults, module communication errors and rack configuration mismatches. It can export configuration reports and event logs for project archive and equipment file management. This software works cooperatively with all series 3500 monitor cards, relay modules, TDI communication cards and I/O termination boards, supporting TMR triple redundant rack project configuration. It runs on Windows operating system, and the version 129133-01 is a stable release version for 3500 rack commissioning. It is widely applied in petrochemical, power generation and metallurgy industries, used for configuration, debugging and maintenance of steam turbines, gas turbines and centrifugal compressors 3500 machinery protection monitoring rack.

Brand: Bently Nevada

Model:3500/01-129133-01

Product Type:3500 Rack Configuration Software

Function:Hardware configuration,alarm setup,parameter download,diagnosis,report export

Feature:Offline configuration,online monitoring,event log reading,TMR rack supported,project report export,compatible with all 3500 series modules

Application:Bently Nevada 3500 TSI machinery protection rack commissioning and maintenance
