Product Details

ABB UFC718AE01 HIEE300936R0001 is an I/O interface board for ABB UNITROL 6000 generator excitation systems and AC800PEC power electronic control platforms. The I/O interface board collects analog and digital field signals, processes the input data, and transmits control signals between the main processor unit and on-site sensors, actuators and switch components. This ABB UFC718AE01 board is equipped with opto-isolated digital channels and high-precision analog channels, which can effectively isolate surge and electromagnetic interference from field equipment and protect core control hardware. The UNITROL 6000 excitation system signal unit has built-in self-diagnostic function and LED status indicators, which can monitor channel status, communication link and internal circuit faults in real time and trigger alarm signals for fast troubleshooting. Conformal coated circuit board improves resistance to moisture, dust and vibration, maintaining stable operation in harsh power plant cabinet environments. Widely used in power plant generator excitation cabinets, medium voltage converters and power quality control equipment, it is critical spare part for power electronic system maintenance, upgrade and renovation. Rack plug-in structure enables convenient installation and quick field replacement.

Parameters and Specifications

Brand: ABB

Model: UFC718AE01 HIEE300936R0001

Product Type: I/O Interface Board

Compatible System: ABB UNITROL 6000 excitation system, AC800PEC platform

Channels: 16 digital inputs, 8 digital outputs, 4 analog inputs, 2 analog outputs

Signal Isolation: Opto signal isolation

Power Supply: 24V DC

Operating Temperature: -20°C ~ +70°C

Protection Class: IP20

Condition: New or tested used spare parts
