Product Details:

TRICONEX 24765-01-01 is a TMR safety control module for Triconex safety instrumented systems (SIS). This TMR safety module receives interlock logic commands from the safety controller and transmits control signals to field actuators and detection devices, completing signal transmission and circuit protection within the safety rack. The module adopts triple modular redundant 2-out-of-3 voting architecture, which can maintain normal operation when one internal channel fails and eliminate single point failure risk. It has built-in continuous self-diagnosis function, capable of detecting circuit open circuit, short circuit and power abnormal state, and uploading fault alarm information to the safety controller in real time. The module supports hot swap operation, maintenance personnel can replace the faulty module online without shutting down the whole safety system, reducing system downtime. It cooperates with Tricon main chassis, I/O modules and matched shielded cable assemblies. Widely applied in oil & gas, petrochemical, chemical and power industries, this TRICONEX 24765-01-01 safety control module undertakes signal transmission and circuit protection work for ESD emergency shutdown, fire and gas detection and burner management safety interlock systems.

Specifications:

Manufacturer: TRICONEX

Model: 24765-01-01

Product Type: Tricon Safety Control Module

Safety Level: SIL3 capable

Feature: Triple modular redundancy, hot swappable, per-channel fault self-diagnosis, reliable signal transmission, rack mount design

Operating Temperature: 0℃ ~ +60℃

Humidity: 5% to 95% non-condensing
