Product Details: Bently Nevada 9200-01-05-10-00 is a self-generating two-wire Seismoprobe Velocity Transducer adopting moving coil principle, no external power supply required, designed for absolute casing vibration measurement of rotating machinery. This Seismoprobe Vibration Sensor outputs voltage signal directly proportional to vibration velocity, which can connect to rack monitoring modules or portable vibration analyzers to continuously collect bearing housing vibration data. The standard sensitivity is 20 mV/mm/s (500 mV/in/s), tolerance within ±5%. According to ordering code 9200-01-05-10-00, this transducer uses 1/2-20 UNF stud mounting thread and equipped with 2-pin Mil-spec circular connector, supports multi-angle installation orientation and does not carry hazardous area certification. The operating temperature range is -29℃ ~ +121℃, suitable for high temperature machine casing environments. Its frequency response covers 10Hz ~ 1kHz, transverse sensitivity ≤10%, and can withstand 50g transverse mechanical impact. During installation, the sensor housing must be fastened tightly on machine casing surface, keep the sensitive axis aligned with vibration measurement direction, loose mounting will cause signal distortion and measurement error. It can match with 9571 series shielded interconnect cable for signal transmission, signal cable needs to be separated from high-voltage power cables to reduce electromagnetic interference. Regular maintenance includes visual inspection of housing corrosion, thread damage, cable sheath aging and connector looseness. Periodic calibration can be implemented on vibration shaker. Widely used in power generation, petrochemical and heavy industrial fields, this Absolute Vibration Transducer monitors turbines, centrifugal compressors, generators, fans and pumps, tracks casing vibration trend changes at early stage, protects bearing components and avoids catastrophic mechanical failure and unplanned equipment shutdown.

Core Attributes:

Brand: Bently Nevada

Model: 9200-01-05-10-00

Product Type: Seismoprobe Two-Wire Velocity Transducer

Sensitivity: 20 mV/mm/s (500 mV/in/s), ±5%

Frequency Response: 10Hz ~ 1kHz

Mounting Thread: 1/2-20 UNF stud mount

Connector: 2-pin Mil-spec circular connector

Measurement Principle: Self-generating moving coil

Features: No external power supply, absolute casing vibration measurement, high impact resistance, wide temperature range, low transverse sensitivity
