Product Details:

The ABB PU519 3BSE018681R1 real-time accelerator board, also known as RTA board, is equipped with dual channel MB300 bus interface for ABB Advant OCS and System 800xA DCS system. This real-time accelerator board adopts PCI card design, installed on engineering workstation, undertaking high-speed MB300 bus data transmission and real-time signal processing tasks independently, reducing the load of workstation CPU. It supports redundant cable monitoring function, realizes stable data communication between engineering computer and Advant controller rack, and is used for system configuration, online monitoring, real-time data reading and hardware diagnosis. It has built-in circuit self-test and anti-electromagnetic interference function to maintain reliable communication in heavy industrial field environment. As essential industrial spare parts, it can replace faulty real-time accelerator board to restore MB300 bus connection and real-time data interaction function of DCS engineering workstation and minimize production downtime.

Product Application:

This Advant OCS DCS module is widely used in power industry,metallurgy,oil and gas,pulp and paper,water treatment and process automation projects. It serves as the dedicated high-speed communication accelerator card of Advant control platform,realizing real-time data exchange and online system debugging between engineering workstation and DCS controller rack.

Parameters and Specifications:

Brand: ABB

Model: PU519 3BSE018681R1

Product Type: Real-Time Accelerator (RTA) Board

Series: Advant OCS, System 800xA

Communication Interface:Dual channel MB300 bus, PCI interface

Power Supply:5V PCI power supply

Feature: Dual MB300 channel, redundant cable supervision, self-test function

Protection Class:IP20

Mounting:PCI slot installation in workstation

Operating Temperature:0℃~+60℃

Storage Temperature:-40℃~+85℃

Weight:0.40kg

Dimension:325mm ×126mm ×17mm

Certification:CE,RoHS

Our ABB PU519 3BSE018681R1 real-time accelerator board is fully inspected and tested before shipment. We supply reliable industrial spare parts with fast global delivery and professional technical support. Please send your inquiry if you need this Advant OCS DCS module.
