Product Details:

The ABB DSDP140B 57160001-ACX pulse counter board is a high-speed signal acquisition and positioning module for ABB Advant Master DCS system. This pulse counter board supports 1 channel of high frequency pulse input up to 80kHz, 2 digital input channels, 4 digital output channels and 1 analog output channel. It converts pulse signals from encoders and speed sensors into digital data, and realizes position closed-loop control and speed measurement. The module adopts anti-electromagnetic interference circuit design to ensure stable signal collection in industrial field environment. As essential industrial spare parts, it can replace faulty pulse counter board to restore position and speed measurement function of the DCS system and minimize production downtime.

Product Application:

This Advant Master DCS module is widely used in power industry,metallurgy,oil and gas,pulp and paper,water treatment and manufacturing process automation. It serves as the front pulse acquisition unit of DCS platform,realizing generator speed monitoring,mechanical position control and motion feedback for on-site industrial equipment.

Parameters and Specifications:

Brand: ABB

Model: DSDP140B 57160001-ACX

Product Type: Pulse Counter Board

Series: Advant Master DCS

Power Supply:24V DC

Input Channels:1 pulse input,2 digital inputs

Output Channels:4 digital outputs,1 analog output

Max Pulse Frequency:80kHz

Communication Interface:ModuleBus backplane bus

Protection Class:IP20

Mounting: Rack mount

Operating Temperature:0℃~+60℃

Storage Temperature:-40℃~+85℃

Weight:0.50kg

Dimension:165mm ×100mm ×30mm

Certification:CE,RoHS

Our ABB DSDP140B 57160001-ACX pulse counter board is fully inspected and tested before shipment. We supply reliable industrial spare parts with fast global delivery and professional technical support. Please send your inquiry if you need this Advant Master DCS module.
