Product Details:

The ABB 5SHX2645L0004 3BHL000389P0104 3BHB003154R0101 5SXE05-0156 IGCT module is a reverse conducting IGCT power semiconductor component with press-pack packaging, used for ABB medium voltage drive and power conversion systems. This IGCT module adopts high power integrated design, supporting fast turn-on and turn-off switching function, with high current carrying capacity and low switching loss. It works with gate drive unit to receive optical fiber trigger signals and control the on-off of high voltage power circuit. The double-sided pressure cooling structure supports water cooling or forced air cooling, which can dissipate heat efficiently under heavy load working conditions. It has built-in surge current resistance and circuit protection performance, suitable for high-power energy conversion occasions. As essential industrial spare parts, it can replace faulty IGCT module to restore power conversion function of medium voltage drive system and minimize production downtime.

Product Application:

This power semiconductor module is widely used in power industry,metallurgy,oil and gas,wind power generation,water treatment and medium voltage variable frequency drive projects. It serves as the core power switching device of high power converter platform,realizing AC-DC power conversion and motor speed regulation for on-site heavy-duty industrial equipment.

Parameters and Specifications:

Brand: ABB

Model:5SHX2645L0004,3BHL000389P0104,3BHB003154R0101,5SXE05-0156

Product Type:Reverse Conducting IGCT Module

Package:Press-pack

Voltage Rating:4500V

Controllable Turn-off Current:2645A

Cooling Method:Water cooled / forced air cooled

Communication Interface:Fiber optic trigger

Protection Class:IP20

Mounting:Press stacking mounting

Operating Temperature:-40℃~+125℃

Storage Temperature:-40℃~+85℃

Weight:2.6kg

Certification:CE,RoHS

Our ABB 5SHX2645L0004 IGCT module is fully inspected and tested before shipment. We supply reliable industrial spare parts with fast global delivery and professional technical support. Please send your inquiry if you need this power semiconductor module.
